Logarithmic profile

Scroll Prev Top Next More

For the logarithmic profile the length of the unmodified cylinder and the amount of crowning has to be defined.

The profile is calculated as:


Using Pr = 0.0005*Dw and Lwu = Lwe – 2.5*Dw leads to the default profile according ISO/TS 16281 for long rollers.
